- STANDARD FEATURES:
- • Complete with pressure gauge and pressure regulator. .
- • Adjustable speed and stroke control.
- • Pressure reversal switch.
- • Ram travel is guided by 4 precision-ground chromed rods.
- • Jog mode used for simplifying setups.
- • Control - your choice of using:
- (1) Moveable pedestal c/w dual electric palm buttons
- (2) Foot pedal
- • P.L.C. programmable control system.
- • Quality BALDOR motor, low speed.
- • Remote hydraulic power Pac with a 100 gal. oil reservoir.
- • All hydraulic and mechanical parts are standard in the industry
- and available throughout North America.
SPECIFICATIONS:
Back to 4-Post Presses
| Rating Motor Approach Speed Press Speed Return Speed Table Press Surface Left to Right Table Press Surface Front to Back Daylight Maximum Stroke (Adjustable) Dimensions Weight |
250 Tons 50 HP 78 IPM 27 IPM 117" 48" 36" 26" 8" H 98.75" 15,200 Lbs |
